Stainless steel flexible pipe 1/2" M x 3/8" F INOX series
ATCIN05020205
Stainless steel flexible pipe 1/2" M x 3/8" F INOX series
AISI 304-DN 10 stainless steel flexible pipe, INOX collection. Ø 14 mm 7 wires, 1/2” M x 3/8” F connection, 20 cm length, complete with washer. Ideal for sanitary application.
Available sizes: 20 cm, 25 cm, 30 cm, 35 cm, 40 cm, 45 cm, 50 cm, 60 cm, 70 cm, 80 cm, 100 cm.
FEATURES: MADE IN ITALY, AISI 304-DN 10 stainless steel flexible pipe Ø 14 mm 7 wires, 20 cm length, 1/2” M x 3/8” F connection, EPDM inner pipe, nickel plated brass fittings, AISI 304 stainless steel sleeves stapled 0,22 mm thickness, 3/8" rubber gasket included, operating temperature from -4° to +90°, max working pressure: 15 BAR, burst pressure: 80 BAR, curvature radius: 45 mm, water consumption: 63 lt/min-3 BAR, high resistance, 5 years warranty, plastic bag packed.
Available sizes
ATCIN05020205
Stainless steel flexible pipe 1/2" M x 3/8" F INOX series 20cm
ATCIN05025205
Stainless steel flexible pipe 1/2" M X 3/8" F INOX series 25cm
ATCIN05030205
Stainless steel flexible pipe 1/2" M X 3/8" F INOX series 30cm
ATCIN05035205
Stainless steel flexible pipe 1/2" M X 3/8" F INOX series 35cm
ATCIN05040205
Stainless steel flexible pipe 1/2" M X 3/8" F INOX series 40cm
ATCIN05045205
Stainless steel flexible pipe 1/2" M X 3/8" F INOX series 45cm
ATCIN05050205
Stainless steel flexible pipe 1/2" M X 3/8" F INOX series 50cm
ATCIN05060205
Stainless steel flexible pipe 1/2" M X 3/8" F INOX series 60cm
ATCIN05070205
Stainless steel flexible pipe 1/2" M X 3/8" F INOX series 70cm
ATCIN05080205
Stainless steel flexible pipe 1/2" M X 3/8" F INOX series 80cm
ATCIN05100205
